Jacketed Fire Survival MI Wiring Cable

Pyrotenax Jacketed Fire Rated Cable is a range of mineral insulated (MI) fire-rated wiring cables with a low smoke zero halogen (LSZH) outer jacket, to ensure critical circuit survival for extended periods when exposed to extreme fire environments. Available in light duty (500 V) and heavy duty (750 V) versions, with solid and twisted copper conductors from 1.0 mm² to 240 mm². A full range of complementary accessories and tools provides a complete wiring system.

Detaljer

Funksjoner

  • Ultimate performance: fireproof, low smoke zero halogen (LSZH), high mechanical strength and corrosion resistance, waterproof and non-ageing
  • Survives the fire test requirements for enhanced grade cables as defined in BS 5839: part 1
  • Peace of mind from the third party (LPCB) approval for categories C, W and Z in BS 6387 (attains categories C, W and Z of BS 6387 with one single cable sample)
  • Reliable during long life: 30 year product warranty available

Spesifikasjoner

Leder Category: Class 1 = Solid
Ledermateriale: Copper
Leder Surface: Bare
Isolasjonsmateriale: Magnesium Oxide
Maks. Leder Temperatur: 842 °F
Nominell spenning U: 750 V
Nominell Spenning U0: 450 V
ytterkappe farge: Black
Permitted Outer Temperatur: 1706 °F
